4.ProductSpecications
This section describes the functionalities of the Industrial Ring Ethernet Switch’s
components and guides you to installing the Switch.
Model IFGS-1222TF IFGS-620TF IFGS-624PTF
HardwareSpecications
Copper Ports
8 x 10/100BASE-TX
RJ45 TP Auto-MDI/
MDI-X, auto-
negotiation
4 x 10/100BASE-TX RJ45 TP Auto-MDI/
MDI-X, auto-negotiation
2 x
10/100/1000BASE-T
RJ45 TP
PoE+ Injector
Ports
NA NA
Four ports with
802.3at PoE+ injector
function (Ports 1 to 4)
SFP Slots 2 x 1000BASE-X SFP interfaces
DIP Switch
OFF: Fiber port Ring
mode
ON: Fiber port
Switch mode
OFF: Fiber port Ring
mode
ON: Fiber port
Switch mode
DIP 1-4:
OFF: Standard mode
ON: Port 1-4 Extend
mode
DIP-5:
OFF: Fiber port Ring
mode
ON: Fiber port Switch
mode
Note:
1.PowerotheIndustrialRingEthernetSwitchbeforeadjusting
the DIP switch and then power it on.
2. Extend mode: PoE transmission distance of 250m at speed of
10Mbps. (IFGS-624PTF).
3. The Ring function can connect to a simple Ring network with up
to 8 units; the recovery time of data link can be as fast as 1ms.
4.Ringperformancemayvarydependingonthelengthoftheber
optic and UTP cables
5. The active Ring function is not compatible with the IEEE 802.1p
class of service function.
Connector
Removable 6-pin terminal block
Pin 1/2 for Power 1; Pin 3/4 for fault alarm; Pin 5/6 for Power 2
