User’s Manual of ICA-x80 series
37
Port
In the main interface, click "Config Network Basic Setup TCP/IP" to enter the TCP/IP
setting interface, where you can set the IP Camera network port and protocol port. The network port
has HTTP port (default is 80), RTSP port (default is 554), HTTPS port (default is 443), and
BITVISION port (default is 6000). The protocol port has the ONVIF port (default is 8999), as shown
in Figure 8-6 ②.
Figure 8-6 ②
【BITVISION Port】When the BitVision App is directly connected to the device, the "Private port" is
entered into the BITVISION port.
【ONVIF Port】 When the IP Camera accesses ONVIF agreement with the back-end equipment,
the ONVIF protocol needs to be enabled.
Please do not arbitrarily modify the port parameters; when there is a port conflict,
you need to modify the port number as follows:
HTTP and HTTPS port: Use the browser login to add the address after the
port number. You need tp enter the HTTP port number (for example, 8555)
that you want to change via the browser login.http://192.168.1.168:8555.
Make sure RTSP port (real-time transmission protocol port) is available for
modification.
In ICA-3480/ICA-4480, the ONVIF port is set to match the HTTP port, the default
value is 80. Modifying the HTTP port will automatically change the ONVIF port as
well.
