User’s Manual of GS-6322 Managed Switch Series
63
4.1 Main Web Page
The Managed Switch provides a Web-based browser interface for configuring and managing it. This interface allows you to
access the Managed Switch using the Web browser of your choice. This chapter describes how to use the Managed Switch’s
Web browser interface to configure and manage it.
Figure 4-1-1: Web Main Page
Panel Display
The web agent displays an image of the Managed Switch’s ports. The Mode can be set to display different information for the
ports, including Link up or Link down. Clicking on the image of a port opens the Port Statistics page.
The port status is illustrated as follows:
State
Disabled
Down
Link
RJ45 Ports
SFP Ports
Help Button
Copper Port tatus
SFP/SFP+ Port Link
Status
Main Functions
Menu
