User’s Manual of GS-6322 Managed Switch Series
44
10Gbps SFP+ (10GBASE-BX, Single Fiber Bi-directional SFP)
Model
DDM
Speed
(Mbps)
Connector
Interface
Fiber Mode
Distance
Wavelength
(TX)
Wavelength
(RX)
Operating
Temp.
MTB-LA20
MTB-LB20
YES
10G
WDM(LC)
Single Mode
20km
1270nm
1330nm
0 ~ 60 ℃
10G
WDM(LC)
Single Mode
20km
1330nm
1270nm
0 ~ 60 ℃
MTB-LA40
MTB-LB40
YES
10G
WDM(LC)
Single Mode
40km
1270nm
1330nm
0 ~ 60 ℃
10G
WDM(LC)
Single Mode
40km
1330nm
1270nm
0 ~ 60 ℃
MTB-LA60
MTB-LB60
YES
10G
WDM(LC)
Single Mode
60km
1270nm
1330nm
0 ~ 60 ℃
10G
WDM(LC)
Single Mode
60km
1330nm
1270nm
0 ~ 60 ℃
It is recommended to use PLANET SFP/SFP+ on the Managed Switch. If you insert an SFP/SFP+
transceiver that is not supported, the Managed Switch will not recognize it.
1. Before p44-we connect the PLANET GS-6322 Series to the other network device, p44-we have to make sure both sides of the
SFP transceivers are with the same media type, for example: 1000BASE-SX to 1000BASE-SX, 1000BASE-LX to
1000BASE-LX.
2. Check whether the fiber-optic cable type matches with the SFP transceiver requirement.
➢ To connect to 1000BASE-SX SFP transceiver, please use the multi-mode fiber cable with one side being the male
duplex LC connector type.
➢ To connect to 1000BASE-LX SFP transceiver, please use the single-mode fiber cable with one side being the male
duplex LC connector type.
◼ Connecting the Fiber Cable
1. Insert the duplex LC connector into the SFP/SFP+ transceiver.
2. Connect the other end of the cable to a device with SFP/SFP+ transceiver installed.
3. Check the LNK/ACT LED of the SFP/SFP+ slot on the front of the Managed Switch. Ensure that the SFP/SFP+
transceiver is operating correctly.
4. Check the Link mode of the SFP/SFP+ port if the link fails. To function with some fiber-NICs or Media Converters, user
has to set the port Link mode to “10G Force”, or “1000M Force”.
◼ Removing the Transceiver Module
1. Make sure there is no network activity anymore.
2. Remove the Fiber-Optic Cable gently.
3. Lift up the lever of the MGB module and turn it to a horizontal position.
4. Pull out the module gently through the lever.
