User’s Manual of GS-6322 Managed Switch Series
22
1.4 Product Features
➢ Physical Port
GS-6322-24P4X
◼ 24 10/100/1000BASE-T Gigabit RJ45 copper ports with 24-port IEEE 802.3bt PoE++ injector function
◼ 2 10GBASE-T RJ45 interfaces with auto MDI/MDI-X function
◼ 2 10GBASE-SR/LR SFP+ slots, compatible with 1000BASE-SX/LX/BX SFP and 2.5G SFP transceiver
◼ RJ45 console interface for switch basic management and setup
GS-6322-48UP4X
◼ 48 10/100/1000BASE-T Gigabit RJ45 copper ports with 48-port IEEE 802.3bt PoE++ injector function
◼ 4 10GBASE-SR/LR SFP+ slots, compatible with 1000BASE-SX/LX/BX SFP and 2.5G SFP transceiver
◼ USB Type C console interface for switch basic management and setup
➢ Power Management
◼ Dual redundant modular power supply slots
◼ Supports configurable power operation modes
- Redundant Power Supply (RPS, 1+1): Provides 1+1 power redundancy when two PSUs are installed.
- Extended Power Supply (EPS, 2+0): Provides more power budget by combining two PSUs to share the
maximum power budget
◼ Active-active redundant power failure protection
◼ Backup of catastrophic power failure on one supply
◼ Fault tolerance and resilience
➢ 802.3bt Power over Ethernet
◼ Complies with IEEE 802.3bt Power over Ethernet Plus Plus
◼ Backward compatible with IEEE 802.3at Power over Ethernet Plus
◼ Up to 24 or 48 ports of IEEE 802.3af/IEEE 802.3at/IEEE 802.3bt PoE devices powered
◼ 24 or 48 PoE ports with built-in 802.3bt PoE++ Type-4 90W injector function
◼ Auto detects powered device (PD)
◼ Circuit protection prevents power interference between ports
◼ Remote power feeding up to 100 meters
◼ PoE management features
− Total PoE power budget control
− Per port PoE function enable/disable
− PoE admin-mode control
− PoE port power feeding priority
− Per PoE port power limit
− PD classification detection
− PoE extend mode control to support power feeding up to a distance of up to 200 meters
◼ Intelligent PoE features
− Temperature threshold control
− PoE usage threshold control
− PD alive check
− PoE schedule
