User’s Manual of GS-6322 Managed Switch Series
143
4.2.7.1 Power Configuration
You can use the Web managmenet interface and then System > Power Management > Power Configuration to change the
power configuration.
This page offers many options for you to manage power applications. This page displays power configuration screen in Figure
4-2-6-1 appears.
Figure 4-2-7-1: Power Configuration Screenshot
The page includes the following fields:
Object
Description
• Power Module
Operation Mode
The Managed Switch allows users to configure power module operation mode via
software setting to handle the demands of power redundancy or additional power
to PoE++ ports as needed.
◼ RPS mode: Provides 1+1 power redundancy when two PSUs are installed.
Power budget is the same as that of one PSU
◼ EPS mode: Provides double power budget by combining two PSUs to share
the maximum power budget.
Default setting: EPS mode
• Number of PSUs
Displays the current number of operating PSUs(Power Supply Uint) that is
installed into the power module slot.
The value is 1 or 2
• Effective Number of
PSUs
The effective number of PSUs, taking the 1+1 power redundancy feature into
account.
• PSU Status
Displays the PSU status of Slot 1 and Slot 2, which can be one of the following:
◼ Operational: The PSU is connected and works properly.
◼ Not Present: The PSU is not present.
◼ Not powered: The PSU is present but not connected to the power source.
