User’s Manual of GS-6322 Managed Switch Series
115
4.2.3.3 RMON Event Configuration
Configure RMON Event table on this page. The entry index key is ID; screen in Figure 4-2-3-3 appears.
Figure 4-2-3-3 RMON Event Configuration Page Screenshot
The page includes the following fields:
Object
Description
• Delete
Check to delete the entry. It will be deleted during the next save.
• ID
Indicates the index of the entry. The range is from 1 to 65535.
• Desc
Indicates this event, the string length is from 0 to 127, default is a null string.
• Type
Indicates the notification of the event; the possible types are:
◼ none: The total number of octets received on the interface, including
framing characters.
◼ log: The number of uni-cast packets delivered to a higher-layer protocol.
◼ snmptrap: The number of broad-cast and multi-cast packets delivered to a
higher-layer protocol.
◼ logandtrap: The number of inbound packets that are discarded even the
packets are normal.
• Community
Specify the community when trap is sent, the string length is from 0 to 127,
default is "public".
• Event Last Time
Indicates the value of sysUpTime at the time this event entry last generated an
event.
Buttons
: Click to add a new community entry.
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
