User’s Manual of GS-6322 Managed Switch Series
106
4.2.2.6 SNMPv3 Communities
Configure SNMPv3 communities table on this page. The entry index key is Community. The SNMPv3 Communities screen in
Figure 4-2-2-5 appears.
Figure 4-2-2-6: SNMPv3 Communities Configuration Page Screenshot
The page includes the following fields:
Object
Description
• Delete
Check to delete the entry. It will be deleted during the next save.
• Community Name
Indicates the security name to map the community to the SNMP Groups
configuration. The allowed string length is 1 to 32, and the allowed content is
ASCII characters from 33 to 126.
• Community Secret
Indicates the community secret (access string) to permit access using SNMPv1
and SNMPv2c to the SNMP agent. The allowed string length is 1 to 32, and the
allowed content is ASCII characters from 33 to 126.
• Source IP
Indicates the SNMP access source address. A particular range of source
addresses can be used to restrict source subnet when combined with source
prefix.
• Source Prefix
Indicates the SNMP access source address prefix.
Buttons
: Click to add a new community entry.
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
