User’s Manual of GS-6322 Managed Switch Series
102
The page includes the following fields:
Object
Description
• Trap Config Name
Indicates which trap Configuration's name for configuring. The allowed string
length is 1 to 32, and the allowed content is ASCII characters from 33 to 126.
• Trap Mode
Indicates the SNMP trap mode operation. Possible modes are:
◼ Enabled: Enable SNMP trap mode operation.
◼ Disabled: Disable SNMP trap mode operation.
• Trap Version
Indicates the SNMP trap supported version. Possible versions are:
◼ SNMP v1: Set SNMP trap supported version 1.
◼ SNMP v2c: Set SNMP trap supported version 2c.
◼ SNMP v3: Set SNMP trap supported version 3.
• Trap Community
Indicates the community access string when send SNMP trap packet. The
allowed string length is 0 to 255, and the allowed content is the ASCII characters
from 33 to 126.
• Trap Destination
Address
Indicates the SNMP trap destination address. It allow a valid IP address in
dotted decimal notation ('x.y.z.w').
And it also allow a valid hostname. A valid hostname is a string drawn from the
alphabet (A-Za-z), digits (0-9), dot (.), dash (-). Spaces are not allowed, the first
character must be an alpha character, and the first and last characters must not
be a dot or a dash.
Indicates the SNMP trap destination IPv6 address. IPv6 address is in 128-bit
records represented as eight fields of up to four hexadecimal digits with a colon
separating each field (:). For example, 'fe80::215:c5ff:fe03:4dc7'. The symbol '::'
is a special syntax that can be used as a shorthand way of representing multiple
16-bit groups of contiguous zeros; but it can appear only once. It can also
represent a legally valid IPv4 address. For example, '::192.1.2.34'.
• Trap Destination Port
Indicates the SNMP trap destination port. SNMP Agent will send SNMP
message via this port, the port range is 1~65535.
• Trap Inform Mode
Indicates the SNMP trap inform mode operation. Possible modes are:
◼ Enabled: Enable SNMP trap authentication failure.
◼ Disabled: Disable SNMP trap authentication failure.
• Trap Inform Timeout
(seconds)
Indicates the SNMP trap inform timeout.
The allowed range is 0 to 2147.
• Trap Inform Retry
Times
Indicates the SNMP trap inform retry times.
The allowed range is 0 to 255.
• Trap Probe Security
Engine ID
Indicates the SNMPv3 trap probe security engine ID mode of operation.
Possible values are:
◼ Enabled: Enable SNMP trap probe security engine ID mode of operation.
◼ Disabled: Disable SNMP trap probe security engine ID mode of operation.
