30
UTION
Power/SWC
It is recommended to have the product
professional.
UTION
-
prevent damage to the product, and/or
possible injury.
te
When replacing the fuse, always do so with
the same type and value (15 A).
Note
Unused input/output wires need be
insulated with tape, heat shrink, or crimp
connectors. Never use wire nuts.
Red
SWC Input
, Accessory (+12V)
Yellow, Constant (+12V)
Blue/White
,
R
em. Output (+12v, 500 mA)
Orange
Blue, Antenna Output (+12V, 500 mA Max)
Violet/White,
Reverse Signal Input (+12V)
Black, Ground (-)
Note
A separate interface might be needed for your
consult with a professional installer.
CAUTION
If several ampli ers are to be used, it is
recommended to use a relay for the Remote
Out trigger.
Red/Violet,
(+12V, 500 mA)
Red/White, Rear Camera Power
Front Camera Power
(+12V, 500 mA)
FL
RL
SUB1 SUB2
RADIO
FR
RR
L-IN
R-IN
V-IN
