Installation
1. The built in stand must be extended out in order to access the USB-C/HDMI/earphone inputs
and Power/Menu button.
2. Please ensure that the power cable and other cables are fully and securely inserted to
prevent them from coming loose.
3. Be careful not to bend or pull the cables excessively and avoid placing heavy objects
on them.
4. When using the HDMI port, a separate power source must be connected to one of the
Type-C ports.Use the included adapter and USB-C cable.
5. Default brightness of the portable monitor is set to 30. You can adjust the brightness
using the hotkey (slide up) or in the OSD brightness settings.
6. If the battery is low on the connected device, we recommend powering up the
connected device (Laptop, Mobile Phone, Nintendo Switch) with their original adapters
7. See figures below on how to connect the portable monitor.
8. Recommended resolution and refresh rate is 1920 x 1200 @ 60hz
Connect the USB-C port on the side of the monitor to the USB-C port on your
laptop using a USB-C cable.
When the laptop battery is low, plug in the laptop using the original adapter or a compatible
one made for your laptop.
Note: The adapter included with the Portable Monitor does not provide enough power to
charge your laptop.
USB-C cable
(included)
Original laptop adapter
(Not included)
Fig
1.:
Connecting to a Laptop (USB-C to USB-C)：
Check if
your laptop supports DP
Alt Mode or Thunderbolt
.
