~ 61 ~
K
UPPER CHIMNEY
L
LOWER CHIMNEY
N
SCREWS
O
CHIMNEY BRACKET
11. Install the aluminium grease filter (if not yet installed) and connect the appliance
to the mains
15
. The installation of the aluminium grease filter is described in
chapter 6.1 CLEANING OF THE GREASE FILTERS.
12. Check the correct position of the extractor hood from front and side
perspective (s. fig below). Otherwise, the appliance will not work properly.
RIGHT
WRONG
WARNING! Operate the appliance with inserted grease filters only.
Otherwise, recirculating-transported fat will deposit in the appliance and
the exhaust system. RISK OF FIRE!
2.6 Electrical connection
Check that the voltage indicated on the rating plate matches the mains voltage of
your home before you connect the extractor hood to the mains.
Check that the extractor hood is installed properly before you connect the
appliance to the mains.
15
If the socket is covered by the chimney, you must plug in the appliance at an earlier point in time.
