~ 71 ~
INSTALLATION OF THE INDUCTION HOB
1. Before installing the induction hob, you must fix the adhesive seal
14
on the
bottom edge of the induction hob properly (s. fig. below).
The seal must be fitted tightly on the bottom edge of the induction hob (no
overlaps, no gaps etc.) to prevent liquids etc. from entering the installation
opening subsequently.
Fig. similar.
1
SEAL
2
HOB
3
WORKTOP
4
OUTER EDGE OF THE INDUCTION HOB
5
OUTER SIDE OF THE SEAL
6
BOTTOM OF THE INDUCTION HOB
2. Install the fixing brackets on the housing of the appliance (s. the following
description).
HOW TO INSTALL THE FIXING BRACKETS
a. Place the appliance on a stable and soft surface (use the packaging).
b. Do not exert any physical force to the control elements of the appliance.
c. Install the fixing brackets on the sides of the induction hob using the
corresponding screws: screw one end of the fixing brackets into the pre-drilled
holes (as shown in the fig. below).
14
Depending on model.
