2.4 Device view
Fig. similar: Fig. serve only as an example.
1
HOUSING OF THE EXTRACTOR HOOD
2
CONTROL PANEL
3
EXHAUST AIR OUTLET
4
NON-RETURN FLAP
5
EXHAUST AIR HOSE (only for exhaust air operation)
6
OUTER CHIMNEY
7
INNER FIREPLACE
2.5 Installation : Non-return flap / extractor hood
WARNING! For safety reasons, only use fastening or installation
screws in the sizes specified in these operating instructions. Failure to
observe the size and installation instructions for screws or fastening
devices can result in electric shock! RISK OF ELECTRIC SHOCK!
WARNING! Do not damage any electrical cables in the walls when
drilling. RISK OF ELECTRIC SHOCK!
NOTE! You will need two more people to install the appliance.
NOTE! Any damage caused by an improperly installed and/or
improperly connected device is not covered by the guarantee or warranty.
We recommend having the extractor hood installed by qualified specialists. Any
damage caused by improper installation of the appliance is not covered by the
guarantee or warranty.
