2.1.2 The relation curve of PRESSURE-TEMPERATURE
WYT009GLSI24RL
WYT009ALSI24RL
WYT012GLSI24RL
f(Hz)
HP
LP
f(Hz)
HP
LP
f(Hz)
HP
LP
(MPa/psi)
(MPa/psi)
(MPa/psi)
(MPa/psi)
(MPa/psi)
(MPa/psi)
35
℃（
95
℉
）
Cooling
70
2.06/298.78
0.98/142.13
70
2.01/291.52
0.96/139.23
80
2.02/292.97
0.99/143.59
43
℃（
109.4
℉
）
Cooling
66
2.54/368.4
1.02/147.94
64
2.5/362.59
0.97/140.69
78
2.51/364.04
1.01/146.48
48
℃（
118.4
℉
）
Cooling
54
2.88/417.71
1.21/175.49
56
2.83/410.45
1.15/166.79
70
2.9/420.6
1.17/169.69
7
℃（
44.6
℉
）
Heating
72
2.15/311.83
0.67/97.17
72
2.29/332.13
0.66/95.72
86
2.4/348.09
0.68/98.62
WYT012ALSI24RL
WYT018GLSI24RL
WYT024GLSI24RL
f(Hz)
HP
LP
f(Hz)
HP
LP
f(Hz)
HP
LP
(MPa/psi)
(MPa/psi)
(MPa/psi)
(MPa/psi)
(MPa/psi)
(MPa/psi)
35
℃（
95
℉
）
Cooling
74
1.94/281.37
0.98/142.14
80
2.78/403.2
0.79/114.58
80
2.54/368.39
0.65/94.27
43
℃（
109.4
℉
）
Cooling
64
2.45/355.34
1.05/152.28
76
3.1/449.6
0.85/123.3
74
2.97/430.71
0.73/105.88
48
℃（
118.4
℉
）
Cooling
54
2.88/417.7
1.24/179.84
66
3.39/491.68
0.99/143.59
66
3.31/480.1
0.86/124.7
7
℃（
44.6
℉
）
Heating
84
2.17/314.73
0.69/100.08
88
2.87/416.25
0.58/84.12
80
3.23/468.5
0.99/143.58
Note:
The test under condition:
Rated Cooling: IDU dry bulb27℃/ Wet bulb 19℃, ODU dry bult35℃/ wet bulb 24℃;The connection pipes: 5m.
Rated Heating: IDU dry bulb20
℃
/ Wet bulb 15
℃
, ODU dry bult7
℃
/ wet bulb 6
℃
;The connection pipes: 5m.
Important:
The above data under test standard in the lab, the HP (High pressure) and LP (Low pressure) will vary along with the
variation of operation frequency, ambient temperature and\or fan speed.
2.1.3The relation curve of NOISE-OPERATION FREQUENCY
