Air Conditioner Service Manual
5
2.1.2 The Relation Curve of Pressure-Temperature
WYT009GLSI20RL WYT009ALSI20RL WYT012GLSI20RL WYT009ALSI20RL
f(Hz)
HP
LP
f(Hz)
HP
LP
f(Hz)
HP
LP
f(Hz)
HP
LP
(MPa/psi)
(MPa/psi)
(MPa/psi)
(MPa/psi)
(MPa/psi)
(MPa/psi)
(MPa/psi)
(MPa/psi)
35
℃ |
95
℉
Cooling
70
2.34
/339.39
0.94
/136.34
70
2.39
/346.64
1.05
/152.29
78
1.97
/285.72
1.06
/153.74
78
1.92
/278.47
1.13
/163.89
43
℃ |
109
℉
Cooling
62
2.92
/423.51
1.02
/147.94
62
3.00
/435.11
1.08
/156.64
68
2.37
/343.74
1.00
/145.04
66
2.35
/340.84
1.01
/146.49
48
℃ |
118
℉
Cooling
54
3.32
/481.53
1.29
/187.1
54
3.32
/481.52
1.29
/187.1
54
2.73
/395.95
1.21
/175.49
56
2.67
/387.25
1.19
/172.59
7
℃ |
45
℉
Heating
78
2.12
/307.48
0.61
/88.47
78
2.12
/307.48
0.61
/88.47
78
2.36
/342.29
0.67
/97.18
78
2.36
/342.29
0.67
/97.18
WYT018GLSI20RL WYT024GLSI20RL WYT030GLSI20RL WYT036GLSI20RL
f(Hz)
HP
LP
f(Hz)
HP
LP
f(Hz)
HP
LP
f(Hz)
HP
LP
(MPa/psi)
(MPa/psi)
(MPa/psi)
(MPa/psi)
(MPa/psi)
(MPa/psi)
(MPa/psi)
(MPa/psi)
35
℃ |
95
℉
Cooling
84
2.86
/414.81
0.687
/99.64
84
2.93
/424.96
0.787
/114.1
96
2.717
/394.07
0.686
/99.49
96
2.717
/394.07
0.686
/99.49
43
℃ |
109
℉
Cooling
82
3.163
/458.75
0.71
/102.98
82
3.404
/493.71
0.803
/116.46
84
3.173
/460.2
0.765
/110.95
84
3.173
/460.2
0.765
/110.95
48
℃ |
118
℉
Cooling
74
3.524
/511.11
0.878
/127.34
68
3.748
/543.6
0.979
/141.99
68
3.448
/500.09
0.956
/138.65
68
3.448
/500.09
0.956
/138.65
7
℃ |
45
℉
Heating
92
2.56
/371.3
0.537
/77.89
96
2.63
/381.45
0.564
/81.80
90
2.514
/364.62
0.557
/80.78
90
2.514
/364.62
0.557
/80.78
Note:
The test under condition:
Rated Cooling: IDU Dry Bulb 81°F / Wet Bulb 66°F / ODU Dry Bulb 95°F / Wet Bulb 75°F / Connection Pipes: 16.4ft
Rated Heating: IDU Dry Bulb
68°F
/ Wet Bulb
59°F
/ ODU Dry Bulb
45°F
/ Wet Bulb
43°F
/ Connection Pipes: 16.4ft
Important:
The above data under test standard in the lab, the HP (high pressure) and LP (low pressure) will vary along with the
variation of operation frequency, ambient temperature, and\or fan speed.
