3

www.pioneerelectronics.com

Using the SP-C22 as a Center Speaker

The loudspeaker may be positioned above or below the TV.

Forbestresultsalignthefrontoftheloudspeakerwiththe

frontoftheTV.Duetothewell-controlledverticaldirectivity,

it is not normally necessary to vertically aim the loudspeaker

towardsthelistener.If,however,theloudspeakerisplaced

undertheTVandveryclosetotheoor,thentiltingupwards

may be beneficial.

Follow the instruction for your receiver and set the center

channeltoNORMALinPrologicmodes,orSMALLinDolby

andDTSmodes.Thiswillensurethatanybasssignals

encoded in the center channel are redirected to the front

speakersorsub-wooferwheretheywillbeoptimally

reproduced.Ifyouhaveachoice,setthecrossover

frequencyto100Hz.

Itisrecommendedtouseasoundlevelmetertosetupthe

center channel level from the receiver. Adjust the receiver

center volume until the center channel sound level is equal

tothatfromthefrontleftandrightloudspeakers.Intheabsenceofameter,initiallysetthelevelofeachchannel

tobeidentical.Allmodelsintherangehavesufcientlyclosesensitivitiessuchthatthisisagoodstarting

point.Nowplayawideselectionofmoviesandlistencarefullytotheclarityofdialog,particularlyinthe

presenceofothereffectssuchasexplosions.Adjusttheleveluntilthedialogisclearlybutnaturallypresented.

For best results the loudspeakers should be positioned at or above ear level.

ENGLISH

USING FEET WITH THE SP-C22

CENTER-CHANNEL SPEAKER

IncludedintheSP-C22cartonare(2)feetfortheSP-C22toreston.

Place the feet at the desired location of the speaker. They can be

spacedavarietyofwidthsapartforinstallationexibility.Oncethe

SP-C22isplacedonthefeet,tiltthespeakertothedesiredangle,

dependingonthelocationofthespeakerinrelationtothedesired

listeningposition.

NOTE: Do not use adhesive or screws to attach the feet to the

speaker. Doing this will damage the cabinet and void the warranty.

PLACEMENT AND FINE TUNING

Correctplacementisimportantformaximizingthesound

qualityofyourloudspeakersystem.Taketimetoexperiment

withpositioningaccordingtotheguidelinesbelow.

Using the SP-FS52 or SP-BS22-LR as Front and

Surround Speakers

For best results the tweeter should be positioned near

ear level and the loudspeakers separated a distance

approximatelyequaltothelisteningdistance.Anglingthe

loudspeakers inward towards the listener will improve the

imagestabilityfornon-centrallisteners.Closeproximity

toasideorrearwallwillenhancethebassperformance,

althoughtooclose(particularlyacornerlocation)andthe

bassmaybeunnaturallyhighandimageperformance

maybedegraded.Bestresultswillbeobtainedwhen

theloudspeakerisplacedapproximately2feetfromthe

wall.Ifacornerlocationisunavoidable,trytopositionthe

loudspeaker so that the distance to the rear wall is not

equal to the distance to the side wall.
