3
WM-1S / WL-1S / WH-1S
English
Specications
Transmitter
WM-1 (Handheld Transmitter) WB-1 (Beltpack Transmitter)
Frequency Range
(Selectable)
500-875MHz (Selectable) 500-875MHz (Selectable)
Housing Material ABS ABS
Bandwidth 25MHz 25MHz
Spurious Emissions <-55dBc <-55dBc
Max. Deviation Range ±68KHz ±68KHz
Maximum Input Level 148dB SPL 148dB SPL
Battery AA×2 Alkaline, >12hr battery life AA×2 Alkaline, >12hr battery life
Notes
Please work with your sales representative to select
the optimal frequency for your region
Receiver
WR-1 (Wireless Receiver)
Frequency Range
(Selectable)
500-875MHz (Selectable)
Oscillation Mode PLL synthesized
Bandwidth 25MHz
Preset Channels 16 Non-interference channels
Receiving Mode CPU-controlled diversity technology
Squelch Control Optimized automatic squelch control
Display Channel display LED, 4 LED RF display, 4 LED AF display
Sensitivity 6dBμV, at S/N>80dB
Max. Deviation Range ±60KHz
Spurious Emissions <80dB
Frequency Response 50Hz~16KHz
S/N Ratio >100dBA
T.H.D. <0.5% @ 1KHz (Dev.=40KHz)
AF Output 300mV rms
Power Supply DC 12~15V
Current Consumption <190 mA
Working Temperature
-10~60℃
Notes
Please work with your sales representative to select the optimal
frequency for your region
