Safari 3000
Front View
1. Retractable Handle: Durable retractable metal handle
2.
Fixed Metal Handle: Top-mounted metal handle
3.
High Frequency Speaker: 1” pure titanium compression horn
4.
Low Frequency Speaker: 10” custom-tuned paper/ber
composite woofer
5.
Speaker Grille: 1.3 mm power-coated steel grille
Rear View
1. Microphone Storage Compartment
Two handheld microphones can be stored inside the integrated
storage compartment.
2. One-Touch Auto-Scan Wireless Microphone Receiver
Modules
Two wireless modules can be installed in the Safari 3000.
3. Safari CD/USB and USBR-1 Modules
Optional CD/USB or USBR-1 modules can be installed onto the
Safari 3000.
4. Channel Volume Controls
Channels 1 through 3 each have dedicated level controls.
5. Neutrik Combo Jacks
Neutrik combo jacks accept both balanced and unbalanced signals
from XLR and ¼” TRS connectors.
6. RCA Input
The RCA input is ideal for connecting iPods, CD/DVD players,
and blu-ray players.
7. Mini Stereo Input
The 1/8” mini stereo jack is identical to those used by portable CD
player, iPod and other MP3 players.
8. Voice Priority
When activated, the voice priority circuitry automatically detects
signals from the microphone inputs and reduces volume from
line inputs as necessary. Voice priority reduces volume from
Channel 3 and the optional CD player, giving priority to microphone
Channels 1 & 2.
9. RCA Output
The RCA output sends the Safari’s combined output signal to
external devices like tape recorders, mp3 recorders or external
mixers.
10. Powered Speakon Output (4 Ohm Minimum Load)
The Safari 3000’s Speakon output powers up to two 8ohm passive
companion speakers (Safari 3000P). Warning: Note the minimum
4 ohm load for this connection.
11. Master Volume Control
Master volume controls the summed output level of the Safari.
2
1
1
2
3
3
4
5
4
5
9
8
10
19
18
20
17
15
16
14
7
13
12
116
