English
5Safari 1000M / Safari 1000 Lite
Specications
Wireless Transmitter Specications
WM-1 (Handheld Transmitter) WB-1 (Beltpack Transmitter)
Frequency Range (Selectable) 500-875MHz (Selectable) 500-875MHz (Selectable)
Housing Material ABS ABS
Bandwidth 25MHz 25MHz
Spurious Emissions <-55dBc <-55dBc
Max. Deviation Range ±68KHz ±68KHz
Maximum Input Level 148dB SPL 148dB SPL
Battery AA×2 Alkaline, >8hr battery life AA×2 Alkaline, >8hr battery life
Wireless Receiver Specications
WR-1 (Wireless Receiver)
Frequency Range (Selectable) 500-875MHz (Selectable)
Oscillation Mode PLL synthesized
Bandwidth 25MHz
Preset Channels 16 Non-interference channels
Receiving Mode CPU-controlled diversity technology
Squelch Control Optimized automatic squelch control
Display Channel display LED, 4 LED RF display, 4 LED AF display
Sensitivity 6dBμV, at S/N>80dB
Max. Deviation Range ±68KHz
Spurious Emissions <80dB
Frequency Response 50Hz~16KHz
S/N Ratio >100dBA
T.H.D. <0.5% @ 1KHz (Dev.=40KHz)
AF Output 300mV rms
Power Supply DC 12~15V
Current Consumption <190 mA
Working Temperature -10~60℃
Safari 1000M Safari 1000 Lite
Amplier Technology Class D Class D
Power Output 50 Watt Peak / 25 Watt RMS 50 Watt Peak / 25 Watt RMS
Power Technology Switching Switching
Driver 5.25" Full Range 5.25" Full Range
Frequency Response 50 Hz - 18 kHz 50 Hz - 18 kHz
Input 1/4" TRS and mini-stereo 1/4" TRS and mini-stereo
Output Mini-stereo Mini-stereo
Battery Indicator 4-phase indicator 4-phase indicator
Body Material Molded Polymer Molded Polymer
USB Recorder/Player Record: WAV; Playback: MP3/WAV Not Included
Microphone
Wireless UHF Microphone
with autoscan, volume control
Wired Microphone
with 3' spiral cable
Battery Spec Lithium 14.8V 2.6AH Lithium 14.8V 2.6AH
Battery Operation Time 10 hours at 80% output 10 hours at 80% output
Dimensions (H×W×D) 170 x 156 × 280 mm (6.7" x 5.5" x 11") 170 x 156 × 280 mm (6.7" x 5.5" x 11")
Weight 1.9 kg (4.1 lbs) 1.7 kg (3.7 lbs)
NOTE: Please work with your sales representative to select the optimal frequency for your region.
