18
DMP8800
English
SPECIFICATIONS
Overall Sonic Performance Analog In, Digital Out Digital In, Analog Out
Frequency Response, 20Hz to 20kHz +/-0.1dB +/-0.25dB
Dynamic Range, 20Hz to 20kHz, unweighted >115dB >114dB
Latency at 48 kHz <1 ms <1ms
Audio Inputs Analog Mic/Line AES/EBU Digital
Input Type Active balanced Euroblock + RCA Transformer balanced female XLR
Input Impedance E: 3.37K, RCA: 8.2K 118 ohms
Max Input Level +20dBu 7�0 Vpp
Audio Outputs Analog Output AES/EBU Digital
Output Type Servo-balanced Euroblock Transformer balanced male XLR
Output Impedance 20 ohms 110 ohms
Max Output Level +20dBu 5�0 Vpp
Word Clock
Input/Output Type 75 ohm BNC
Lock Range 48 kHz +/-4%
Input Impedance Selectable 75 ohm or high impedance
Input Voltage Range 1�0Vpp - 7�0Vpp
Output Impedance 75 ohm BNC
Output Level 5�0 Vpp nominal, unterminated
Master Clock
Sources Audio network, Word clock, AES3, Internal crystal clock
Modes Prioritized auto switching or manual
Digital Audio Hardware
Sampling Rates 44�1kHz, 48kHz ,Network , AES
DSP Processing 40-bit oating-point Share processor array
Audio Input Source Selection
Selectable in adjacent channel pairs from analog,
digital, or network inputs
Network Audio Routing Selectable between input/ouput or internal to matrix mixer
Digital Control
Ethernet Control Standard RJ45 10/100 Ethernet with auto-conguration
7 pin pre-set remote Peripheral for RM6E remote control
Relay 1 set, 5VDC
Analog Control
Remote Attenuators 10-pin Euroblock for (8) assignable 5VDC passive remote attenuators
Power Requirements 100V to 240V VAC, 50-60Hz, 70W maximum
Item Size (L x W x H) 482 x 295 x 95 mm / 18�97” x 37�4” x 11�61”
Item Weight 5.1 Kgs / 11.2 lbs
