20
English
DMP1616 / DMP1616D
I don’t have any output
Have you activated the output channels? Do you see a
signal in the output meters? Have you correctly routed
your inputs to channels, turned levels up, and unmuted
mixes? Have you applied an excessive compressor-
limiter to any input or output signals?
I have a signal, but it’s really distorted!
Are any of the Clip LEDs lighting up for input or output
mixes? Do any of the signals on your entire audio chain
seem excessive? This could include input connectors,
channel inputs, matrix outputs.
My devices are not communicating via Ethernet
Are the red and green LEDs on the Ethernet connectors
lighting up? Are you using a decent quality Ethernet
cable?
My DMP1616 won’t communicate with my computer
Are you using a decent quality Ethernet cable? Are your
computer and DMP1616 both connected to the same
network? Do you have a rewall turned on?
TROUBLESHOOTING
How can I use the RS-232 port?
An RS-232 connection is available on the DMP1616 to
allow control information to be sent to the unit without the
need of Ethernet connection. Asystems has provided an
implementation reference on the website.
Initializing the DMP1616
The DMP1616 can be initialized using the DIP switch on
the rear of the device. The left-most pin will allow users
to begin initializing the unit. It can be returned to the
RESUME position to continue operation.
Why are the front panel VRs not working?
The rear panel has a DIP switch that controls these VRs.
If set to the lower position these will be locked and you
will be unable to use them.
