Installation

107812_en_08 Phoenix Contact 11 / 82

3 Installation

3.1 Product description

The compact TC MOBILE I/O... signaling system uses the cellular network to monitor an-

alog and digital values. The device also switches relay outputs remotely.

The device offers a number of helpful software functions, such as cellular network diag-

nostics and different user roles. A USB connection to a computer with a web browser is

all that is required for configuration.

Applications

– Machine, building, and system monitoring

– Pumps, wastewater treatment plants, water supply

– Lighting control systems, remote switching devices

– Elevators, gates

– Alarm technology and building services

– HVAC technology

– Battery monitoring (up to 60 V)

– Railway applications in accordance with EN 50121-4

Features

– European LTE cellular network, CAT1:

B3 (1800 MHz), B7 (2600 MHz), B20 (800 MHz)

– GSM cellular network: 900 MHz, 1800 MHz

– Event- or interval-controlled communication

– Four digital inputs

– Four relay outputs, can be switched via cellular communication

– DC versions: two scalable analog inputs, can be switched between current and volt-

age

– Standard mini SIM card, LTE-capable

– Compact design: 4 HP in accordance with DIN 43880

– Housing cover can be sealed

– Mounting on a DIN rail or the wall

– SMS alarms in the event of voltage failure

Tabelle 3-1 Product versions

Designation Item No. Cellular

comm.

Voltage Communication

TC MOBILE I/O X200-4G 1038567 4G DC – Text message

(SMS)

– Email

– App (SMS,

HTTPS)

TC MOBILE I/O X200-4G AC 1038568 4G AC
