Register tables

105608_en_02 PHOENIX CONTACT 97

A 1.5 Address area of range 4

Table A-8 Range 4: SCK channel 3 (Modbus addresses 0180h to 01E0h)

Modbus

address

(HEX)

Access Designation Modbus

address

(HEX)

Access Designation

0180 Read-only SCK channel 3,

status

01B0 Read-

only

SCK channel 3,

PD47

0181 Read-only SCK channel 3,

PD0

01B1 Read-

only

SCK channel 3,

MI0

0182 Read-only SCK channel 3,

PD1

01B2 Read-

only

SCK channel 3,

MI1

0183 Read-only SCK channel 3,

PD2

01B3 Read-

only

SCK channel 3,

MI2

0184 Read-only SCK channel 3,

PD3

01B4 Read-

only

SCK channel 3,

MI3

0185 Read-only SCK channel 3,

PD4

01B5 Read-

only

SCK channel 3,

MI4

0186 Read-only SCK channel 3,

PD5

01B6 Read-

only

SCK channel 3,

MI5

0187 Read-only SCK channel 3,

PD6

01B7 Read-

only

SCK channel 3,

MI6

0188 Read-only SCK channel 3,

PD7

01B8 Read-

only

SCK channel 3,

MI7

0189 Read-only SCK channel 3,

PD8

01B9 Read-

only

SCK channel 3,

MI8

018A Read-only SCK channel 3,

PD9

01BA Read-

only

SCK channel 3,

MI9

018B Read-only SCK channel 3,

PD10

01BB Read-

only

SCK channel 3,

MI10

018C Read-only SCK channel 3,

PD11

01BC Read-

only

SCK channel 3,

MI11

018D Read-only SCK channel 3,

PD12

01BD Read-

only

SCK channel 3,

MI12

018E Read-only SCK channel 3,

PD13

01BE Read-

only

SCK channel 3,

MI13

018F Read-only SCK channel 3,

PD14

01BF Read-

only

SCK channel 3,

MI14

0190 Read-only SCK channel 3,

PD15

01C0 Read-

only

SCK channel 3,

MI15

0191 Read-only SCK channel 3,

PD16

01C1 Read-

only

SCK channel 3,

MI16

0192 Read-only SCK channel 3,

PD17

01C2 Read-

only

SCK channel 3,

MI17
