A 1.4 Address area of range 3

Table A-7 Range 3: SCK channel 2 (Modbus addresses 0100h to 0160h)

Modbus

address

(HEX)

Access Designation Modbus

address

(HEX)

Access Designation

0100 Read-

only

SCK channel 2,

status

0130 Read-only SCK channel 2,

PD47

0101 Read-

only

SCK channel 2,

PD0

0131 Read-only SCK channel 2,

MI0

0102 Read-

only

SCK channel 2,

PD1

0132 Read-only SCK channel 2,

MI1

0103 Read-

only

SCK channel 2,

PD2

0133 Read-only SCK channel 2,

MI2

0104 Read-

only

SCK channel 2,

PD3

0134 Read-only SCK channel 2,

MI3

0105 Read-

only

SCK channel 2,

PD4

0135 Read-only SCK channel 2,

MI4

0106 Read-

only

SCK channel 2,

PD5

0136 Read-only SCK channel 2,

MI5

0107 Read-

only

SCK channel 2,

PD6

0137 Read-only SCK channel 2,

MI6

0108 Read-

only

SCK channel 2,

PD7

0138 Read-only SCK channel 2,

MI7

0109 Read-

only

SCK channel 2,

PD8

0139 Read-only SCK channel 2,

MI8

010A Read-

only

SCK channel 2,

PD9

013A Read-only SCK channel 2,

MI9

010B Read-

only

SCK channel 2,

PD10

013B Read-only SCK channel 2,

MI10

010C Read-

only

SCK channel 2,

PD11

013C Read-only SCK channel 2,

MI11

010D Read-

only

SCK channel 2,

PD12

013D Read-only SCK channel 2,

MI12

010E Read-

only

SCK channel 2,

PD13

013E Read-only SCK channel 2,

MI13

010F Read-

only

SCK channel 2,

PD14

013F Read-only SCK channel 2,

MI14

0110 Read-

only

SCK channel 2,

PD15

0140 Read-only SCK channel 2,

MI15

0111 Read-

only

SCK channel 2,

PD16

0141 Read-only SCK channel 2,

MI16

0112 Read-

only

SCK channel 2,

PD17

0142 Read-only SCK channel 2,

MI17
