SOLARCHECK family

88

PHOENIX CONTACT 105608_en_02

A 1.2 Address area of range 1

Table A-5 Register entries for connecting current measuring module 2901672

(Modbus addresses 0000h to 005Fh)

Modbus

address

(HEX)

Access Designation Modbus

address

(HEX)

Access Designation

0000 Read-

only

SCK channel 1,

status

0030 Read-

only

SCK channel 5,

current 4

0001 Read-

only

SCK channel 1,

current 1

0031 Read-

only

SCK channel 5,

current 5

0002 Read-

only

SCK channel 1,

current 2

0032 Read-

only

SCK channel 5,

current 6

0003 Read-

only

SCK channel 1,

current 3

0033 Read-

only

SCK channel 5,

current 7

0004 Read-

only

SCK channel 1,

current 4

0034 Read-

only

SCK channel 5,

current 8

0005 Read-

only

SCK channel 1,

current 5

0035 Read-

only

SCK channel 5,

temperature

0006 Read-

only

SCK channel 1,

current 6

0036 Read-

only

SCK channel 5,

voltage

0007 Read-

only

SCK channel 1,

current 7

0037 Read-

only

SCK channel 6,

status

0008 Read-

only

SCK channel 1,

current 8

0038 Read-

only

SCK channel 6,

current 1

0009 Read-

only

SCK channel 1,

temperature

0039 Read-

only

SCK channel 6,

current 2

000A Read-

only

SCK channel 1,

voltage

003A Read-

only

SCK channel 6,

current 3

000B Read-

only

SCK channel 2,

status

003B Read-

only

SCK channel 6,

current 4

000C Read-

only

SCK channel 2,

current 1

003C Read-

only

SCK channel 6,

current 5

000D Read-

only

SCK channel 2,

current 2

003D Read-

only

SCK channel 6,

current 6

000E Read-

only

SCK channel 2,

current 3

003E Read-

only

SCK channel 6,

current 7

000F Read-

only

SCK channel 2,

current 4

003F Read-

only

SCK channel 6,

current 8

0010 Read-

only

SCK channel 2,

current 5

0040 Read-

only

SCK channel 6,

temperature

0011 Read-

only

SCK channel 2,

current 6

0041 Read-

only

SCK channel 6,

voltage

0012 Read-

only

SCK channel 2,

current 7

0042 Read-

only

SCK channel 7,

status
