Register tables
105608_en_02 PHOENIX CONTACT 83
0013 SCK channel
2, current 8
Ix100 [A] 0043 SCK channel
7, current 1
Ix100 [A]
0014 SCK channel
2, temp.
[°C] 0044 SCK channel
7, current 2
Ix100 [A]
0015 SCK channel
2, voltage
[V] 0045 SCK channel
7, current 3
Ix100 [A]
0016 SCK channel
3, status
Bit mask 0046 SCK channel
7, current 4
Ix100 [A]
0017 SCK channel
3, current 1
Ix100 [A] 0047 SCK channel
7, current 5
Ix100 [A]
0018 SCK channel
3, current 2
Ix100 [A] 0048 SCK channel
7, current 6
Ix100 [A]
0019 SCK channel
3, current 3
Ix100 [A] 0049 SCK channel
7, current 7
Ix100 [A]
001A SCK channel
3, current 4
Ix100 [A] 004A SCK channel
7, current 8
Ix100 [A]
001B SCK channel
3, current 5
Ix100 [A] 004B SCK channel
7, temp.
[°C]
001C SCK channel
3, current 6
Ix100 [A] 004C SCK channel
7, voltage
[V]
001D SCK channel
3, current 7
Ix100 [A] 004D SCK channel
8, status
Bit mask
001E SCK channel
3, current 8
Ix100 [A] 004E SCK channel
8, current 1
Ix100 [A]
001F SCK channel
3, temp.
[°C] 004F SCK channel
8, current 2
Ix100 [A]
0020 SCK channel
3, voltage
[V] 0050 SCK channel
8, current 3
Ix100 [A]
0021 SCK channel
4, status
Bit mask 0051 SCK channel
8, current 4
Ix100 [A]
0022 SCK channel
4, current 1
Ix100 [A] 0052 SCK channel
8, current 5
Ix100 [A]
0023 SCK channel
4, current 2
Ix100 [A] 0053 SCK channel
8, current 6
Ix100 [A]
0024 SCK channel
4, current 3
Ix100 [A] 0054 SCK channel
8, current 7
Ix100 [A]
0025 SCK channel
4, current 4
Ix100 [A] 0055 SCK channel
8, current 8
Ix100 [A]
0026 SCK channel
4, current 5
Ix100 [A] 0056 SCK channel
8, temp.
[°C]
Table A-1 Illustration of the register table for reading 2901672
(Modbus addresses 0000h to 005Ch) [...]
Modbus
address
(HEX)
Name Unit Modbus
address
(HEX)
Name Unit
