A 1.1 Registers – data assignment

Table A-1 Illustration of the register table for reading 2901672

(Modbus addresses 0000h to 005Ch)

Modbus

address

(HEX)

Name Unit Modbus

address

(HEX)

Name Unit

0000 SCK channel

1, status

Bit mask 0030 SCK channel

5, current 4

Ix100 [A]

0001 SCK channel

1, current 1

Ix100 [A] 0031 SCK channel

5, current 5

Ix100 [A]

0002 SCK channel

1, current 2

Ix100 [A] 0032 SCK channel

5, current 6

Ix100 [A]

0003 SCK channel

1, current 3

Ix100 [A] 0033 SCK channel

5, current 7

Ix100 [A]

0004 SCK channel

1, current 4

Ix100 [A] 0034 SCK channel

5, current 8

Ix100 [A]

0005 SCK channel

1, current 5

Ix100 [A] 0035 SCK channel

5, temp.

[°C]

0006 SCK channel

1, current 6

Ix100 [A] 0036 SCK channel

5, voltage

[V]

0007 SCK channel

1, current 7

Ix100 [A] 0037 SCK channel

6, status

Bit mask

0008 SCK channel

1, current 8

Ix100 [A] 0038 SCK channel

6, current 1

Ix100 [A]

0009 SCK channel

1, temp.

[°C] 0039 SCK channel

6, current 2

Ix100 [A]

000A SCK channel

1, voltage

[V] 003A SCK channel

6, current 3

Ix100 [A]

000B SCK channel

2, status

Bit mask 003B SCK channel

6, current 4

Ix100 [A]

000C SCK channel

2, current 1

Ix100 [A] 003C SCK channel

6, current 5

Ix100 [A]

000D SCK channel

2, current 2

Ix100 [A] 003D SCK channel

6, current 6

Ix100 [A]

000E SCK channel

2, current 3

Ix100 [A] 003E SCK channel

6, current 7

Ix100 [A]

000F SCK channel

2, current 4

Ix100 [A] 003F SCK channel

6, current 8

Ix100 [A]

0010 SCK channel

2, current 5

Ix100 [A] 0040 SCK channel

6, temp.

[°C]

0011 SCK channel

2, current 6

Ix100 [A] 0041 SCK channel

6, voltage

[V]

0012 SCK channel

2, current 7

Ix100 [A] 0042 SCK channel

7, status

Bit mask
