SOLARCHECK family

80

PHOENIX CONTACT 105608_en_02

1 – ON

0 – OFF

X – Either

– If other analog devices are connected to the SCK-M-I-8S-20A, you must make sure that

the connected analog device is electrically isolated from the supply of the remaining

SOLARCHECK devices. Otherwise invalid values may occur on the analog input side.

– In the event of communication errors, the communication module is set to the “Timeout”

state after 10 s.

Table 10-14 Baud rates

DIP8 DIP7 DIP6 DIP5 DIP4 DIP3 DIP2 DIP1

Baud rate Parity Number of

stop bits

Not used Stop bit Parity

mode

Activate

parity

Baud

rate

9600 - - X X X X 0 0 0 0

14400 - - X X X X 0 0 0 1

19200 - - X X X X 0 0 1 0

38400 - - X X X X 0 0 1 1

57600 - - X X X X 0 1 0 0

76800 - - X X X X 0 1 0 1

115200 - - X X X X 0 1 1 0

230400 - - X X X X 0 1 1 1

75 - - X X X X 1 0 0 0

150 - - X X X X 1 0 0 1

300 - - X X X X 1 0 1 0

600 - - X X X X 1 0 1 1

1200 - - X X X X 1 1 0 0

2400 - - X X X X 1 1 0 1

4800 - - X X X X 1 1 1 0

7200 - - X X X X 1 1 1 1

- None - X X X 0 X X X X

- Even - X X 0 1 X X X X

- Odd - X X 1 1 X X X X

- - 1 stop bit X 0 X X X X X X

- - 2 stop bits X 1 X X X X X X
