SOLARCHECK family

26

PHOENIX CONTACT 105608_en_02

Different potential levels may occur depending on the structure and connection of the pho-

tovoltaic system. The following voltage ranges can be measured by the device and repre-

sented as an analog value.

The inner range represents the respective analog value that is issued by the device under

the respective voltage conditions.

Table 4-1 Valid voltage ranges – part 1

U+

U- 0 -100 -200 -300 -400 -500 -600 -700

0 2.00 V 2.53 V 3.07 V 3.60 V 4.13 V 4.67 V 5.20 V 5.73 V

100 2.53 V 3.07 V 3.60 V 4.13 V 4.67 V 5.20 V 5.73 V 6.27 V

200 3.07 V 3.60 V 4.13 V 4.67 V 5.20 V 5.73 V 6.27 V 6.80 V

300 3.60 V 4.13 V 4.67 V 5.20 V 5.73 V 6.27 V 6.80 V 7.33 V

400 4.13 V 4.67 V 5.20 V 5.73 V 6.27 V 6.80 V 7.33 V 7.87 V

500 4.67 V 5.20 V 5.73 V 6.27 V 6.80 V 7.33 V 7.87 V 8.40 V

600 5.20 V 5.73 V 6.27 V 6.80 V 7.33 V 7.87 V 8.40 V 8.93 V

700 5.73 V 6.27 V 6.80 V 7.33 V 7.87 V 8.40 V 8.93 V 9.47 V

800 6.27 V 6.80 V 7.33 V 7.87 V 8.40 V 8.93 V 9.47 V 10.00V

900 6.80 V 7.33 V 7.87 V 8.40 V 8.93 V 9.47 V 10.00 V

1000 7.33 V 7.87 V 8.40 V 8.93 V 9.47 V 10.00 V

1100 7.87 V 8.40 V 8.93 V 9.47 V 10.00 V

1200 8.40 V 8.93 V 9.47 V 10.00 V

1300 8.93 V 9.47 V 10.00 V

1400 9.47 V 10.00 V

1500 10.00 V

Table 4-2 Valid voltage ranges – part 2

U+

U- -800 -900 -1000 -1100 -1200 -1300 -1400 -1500

0 6.27 V 6.80 V 7.33 V 7.87 V 8.40 V 8.93 V 9.47 V 10.00 V

100 6.80 V 7.33 V 7.87 V 8.40 V 8.93 V 9.47 V 10.00 V

200 7.33 V 7.87 V 8.40 V 8.93 V 9.47 V 10.00 V

300 7.87 V 8.40 V 8.93 V 9.47 V 10.00 V

400 8.40 V 8.93 V 9.47 V 10.00 V

500 8.93 V 9.47 V 10.00 V

600 9.47 V 10.00 V

700 10.00 V
