SOLARCHECK string current measurement with SCK-M-I-…

105608_en_02 PHOENIX CONTACT 23

Ambient temperature range (operat-

ing)

-20°C ... 70°C

Ambient temperature range (storage) -40°C ... 85°C

Dimensions W / H / D 22.5 mm / 102 mm / 128.5 mm

Screw connection rigid / flexible / AWG 0.2 mm² ... 2.5 mm² / 0.2 mm² ... 2.5 mm² /

24 ... 12

Tightening torque 0.5 Nm… 0.6 Nm

Humidity at 25°C, non-condensing ≤95%

Altitude ≤2000 m

DIN rail installation 35 mm (DIN EN 50022)

Pollution degree 2

Conformance/approvals

Conformance CE-compliant

Conformance with EMC Directive and Low

Voltage Directive

Referenced standard EN 61010-01

EN 61010-2-30

Current measurement SCK-M-I-8S-20A

(2903241)

SCK-M-I-4S-20A

(2903242)
