General notes on the supply of Phoenix Contact signal conditioners

105810_en_02 Phoenix Contact 7 / 56

2 General notes on the supply of Phoenix Contact signal

conditioners

Observe the corresponding packing slip for the relevant products.

NOTE: Connection notes

When using the DIN rail connector, you may only connect one SELV or PELV circuit

to the supply terminals of the modules.

All active signal conditioners from Phoenix Contact can either be supplied directly via ter-

minal blocks on the module or wired individually. Wiring each individual module is very

time-consuming and costly, especially when dealing with large quantities of signal condi-

tioners that are mounted side by side on the DIN rail. This is why, depending on the signal

conditioners used and the supply options, Phoenix Contact offers the option of supplying

a complete standard DIN rail fitted with signal conditioners via a single power terminal by

means of the TBUS DIN rail connector. Time-consuming and error-prone wiring of single-

core wiring is thus eliminated. You can supply the DIN rail connector in the following

ways:

– Direct DC feed-in at any Analog module in the group

– Supply via a power terminal of the same shape

– Supply via any MINI Analog, MINI Analog Pro or MACX Analog power terminal

– Supply via a system power supply with a wide range input of 85 V AC … 264 V AC

All of the power supply methods for MINI Analog, MINI Analog Pro, and

MACX Analog (Ex) modules presented in this manual are compatible with one another.

This means, for example, that as long as the marginal conditions presented in the individ-

ual sections are met, a MINI MCR-2-PTB power terminal can also be used to supply

MACX Analog modules. In addition, if these conditions are met, a combination of different

product ranges can be mounted on a DIN rail.
