MINI Analog supply options

105810_en_02 Phoenix Contact 11 / 56

3 MINI Analog supply options

The MINI Analog signal conditioners require a supply with 24 V DC

(19.2 V DC ... 30 V DC). In addition to supplying individual modules via the corresponding

terminal blocks on the device, various methods for supplying power to several modules

in the MINI Analog product family can be implemented using a DIN rail connector

(ME 6,2 TBUS-2 1,5/5-ST-3,81 GN, item no. 2869728 or

ME 6,2 TBUS-21,5/5-ST-3,81 KMGY, item no. 2969401). It is supplied with 24 V DC and

supplies all connected signal conditioners. This eliminates the need for time-consuming

and costly single-core wiring.

When there are only a few modules mounted side by side, the ideal solution is to supply

the DIN rail connector directly and therefore the connected modules via a signal condi-

tioner, see Section 3.1 on page 12. One way to supply several modules, with or without

short-circuit and cable break detection (see Section 3.4 on page 22), is to use

MINI MCR-SL-PTB… devices (see Section 3.2 on page 14). These devices also support

redundant supply. If a particularly large number of MINI Analog modules need to be

supplied via the DIN rail connector, the MACX MCR-PTB… power and fault signaling

module offers sufficient reserves (see Section 4.2 on page 28).

If there is no 24 V DC supply, the QUINT4-SYS-PS/1AC/24DC/2.5/SC system power

supply presented in Section 3.3 on page 20 (item no. 2904614) can be used. It is suitable

for connection to 230 V AC and is specifically tailored to the requirements of

MCR technology (measurement and control). Use in a potentially explosive area is also

possible.

NOTE: Risk of property damage

Never connect the supply voltage directly to the DIN rail connector.
