1 Functional overview

UPS-CONF is a management software to configure and monitor QUINT-UPS devices, that

come with the IQ technology.

This technology with continuous battery monitoring and intelligent management provides you

with information about the charging state, remaining runtime, and service life of your battery at

all times. Intelligent communication informs you when a situation becomes critical. This

reduces the amount of maintenance involved and increases your system availability.

IQ technology means

• Intelligent Battery Control: automatically detects the connected battery type and

maximizes the remaining service life of the battery unit via an optimally adapted charging

characteristic.

• Intelligent Battery Management: continuous status information is shown for

- SOC (State of Charge): current charging state and remaining back-up time of the

battery unit

- SOH (State of Health): remaining life expectancy of the battery unit, provides early

warning for a potential battery unit failure

- SOF (State of Function): determines the current performance of the battery unit.

• Intelligent Charging: adapts the charging current and thereby ensures the fastest

possible recharging and availability.

• Intelligent communication: the communication of UPS and PC allows configuration,

extensive signaling and parameterization.

The IQ technology also works without UPS-CONF. With this software you have an easier

monitoring and configurations can be done.

The UPS-CONF software is intended for a PC as well as an IPC (Industrial PC). In this

documentation the term "PC" is used to address both.

The configurable QUINT-UPS device is also referred to as the "UPS" in this documentation.

Functional overview

104779_en_01

PHOENIX CONTACT
