IL SYS INST UM E

92 / 188 Phoenix Contact

6452_en_11

Table 8-4 Current and voltage distribution in potential and data jumpers

(120 V AC/230 V AC)

No. Function Voltage to contact* Current

Minimum Maximum Maximum

Potential jumpers

1 7.5 V DC U

L+

7.0 V DC 7.87 V DC 2 A

2 24 V DC U

ANA

19.2 V DC 30 V DC 0.5 A

3 GNDL U

L-

0 V DC 0 V DC 2.5 A

4 120 V AC/230 V

AC

L1 12 V AC 253 V AC 8 A

5 PEN conductor N 0 V 0 V 8 A

6 –

7 PE PE Not defined Not defined Not defined

(9) –

Data jumpers

8 a Bus signal

8 b Bus signal

8 c Clock

* Contact no. 3 is reference potential for the logic.

Contact no. 5 is reference potential for the I/O.
