IL SYS INST UM E

90 / 188 Phoenix Contact

6452_en_11

Depending on the terminal function, not all of the jumpers listed in Figure 8-2 are

present on a terminal. Please refer to the circuit diagram of the terminal to see

which jumpers are available for a terminal and how they are internally connected.

The circuit diagram is shown in the terminal-specific data sheet.

PE

(120 V AC/230 V AC area)

The PE potential jumper is used in the 120 V AC/230 V AC area. It must be connected to

protective ground via the corresponding connection at the power terminal for these volt-

age areas.

Table 8-2 Potential and data jumpers (120 V AC/230 V AC area)

No. Function Meaning

See Figure 8-2 “Basic arrangement of potential and data jumpers” on page 87

Potential jumpers

1 7.5 V DC U

L+

Communications power for the bus interface

2 24 V DC U

ANA

I/O supply for analog terminals

3 GNDL U

L-

Ground of communications power and I/O supply for analog terminals

4 120 V AC/

230 V AC

L1 Phase L1

5 0 V N PEN conductor

6 – Not present

7 PE PE Protective ground

(9) – Not present

Data jumper

8 Local bus
