Structure and dimensions

6452_en_11 Phoenix Contact 69 / 188

6.2.2 Function identification

Housing Apart from their width, Inline Block IO modules have the same appearance in terms of

their housing type and housing color (green).

Function identification The Inline Block IO modules are color-coded to enable visual identification of the func-

tion areas (1 in Figure 6-16).

Figure 6-16 Function identification

The following colors indicate the functions:

Table 6-3 Color-coding of module function areas

Color Module function area

Gray Bus/supply

Light blue Digital input

Pink Digital output

Purple Digital input or output

Green Analog input

Yellow Analog output

U

L

RC

BUS1

BA

RD

BUS2

US1

PWR1

E

U

S

2

PWR2

1

2

3

4

E

O

1

2

3

4

O

2

1

2

3

4

O

3

1

2

3

4

O

4

1

2

3

4

E

I1

1

2

3

4

I2

1

2

3

4

I3

1

2

3

4

I4

1
