IL SYS INST UM E

170 / 188 Phoenix Contact

6452_en_11

A 4.2 Inline ECO terminals

Please also observe the information in the terminal-specific data sheet.

Table A-8 Maximum cable lengths: Temperature recording

Criterion IB IL RTD

4/PT100-ECO

IB IL RTD

4/PT1000-ECO

IB IL UTH

4/J-ECO

IB IL UTH

4/K-ECO

IB IL UTH

4/L-ECO

2702499 2702501 2702502 2702503 2702504

(no longer in

product range)

Number of chan-

nels

4 4 4 4 4

Cable

type/standard

LiYCY(TP)

N x 2 x 0,5

LiYCY(TP)

N x 2 x 0,5

Type J according

to DIN EN 60584-

3

Type K according

to DIN EN 60584-

3

Type L according

to DIN 43710

Maximum cable

length

30 m* 100 m 100 m 100 m 100 m

* Observe the cable resistances when carrying out a tolerance inspection (see termi-

nal-specific data sheet).

Table A-9 Maximum cable lengths: Analog I/O

Criterion IB IL AI

4/I/4-20-ECO

IB IL AI

4/U/0-10-ECO

IB IL AO

4/I/4-20-ECO

IB IL AO

4/U/0-10-ECO

2702495 2702496 2702497 2702498

Number of chan-

nels

4 4 4 4

Cable

type/standard

LiYCY(TP)

N x 2 x 0,5

LiYCY(TP)

N x 2 x 0,5

LiYCY(TP)

N x 2 x 0,5

LiYCY(TP)

N x 2 x 0,5

Maximum cable

length

100 m 100 m 100 m 100 m

Table A-10 Maximum cable lengths: Communication

Criterion IB IL RS 485-ECO IB IL RS 232-ECO

2702141 2702795

Number of chan-

nels

1 1

Cable

type/standard

CAT5 CAT5

Maximum cable

length

according to RS-485 specification depending on the transmission

speed
