Inline: Technical data and ordering data

6452_en_11 Phoenix Contact 155 / 188

General data

This table provides standard data. For different values, please refer to the terminal-specific data sheets.

Instructions Developed according to EN 50178/IEC 62103, UL 508

Ambient temperature

Ambient temperature (operation) - standard versions -25 °C ... +55 °C

Ambient temperature (operation) - XC version -25 °C ... +55 °C (standard)

-40 °C ... +70 °C (extended, see Section “Tested success-

fully: Use under extreme ambient conditions” on page 25

and the data sheet.)

Ambient temperature (operation) - ECO version 0 °C ... +55 °C

Ambient temperature (storage/transport) -25°C … +85°C

Temperature cycles

(Speed of changing from positive to negative temperatures

and vice versa)

0.5 K/min (no condensation)

Permissible humidity (operation/storage/transport) 10 % ... 95% (no condensation)

The humidity requirements have been verified in accor-

dance with

IEC 60068-2-30.

Permissible air pressure (operation/storage/transport) 70 kPa ... 106 kPa (up to 3000 m above sea level)

Degree of protection IP20

Class of protection

Protective extra-low voltage (24 V DC ... 60 V DC,

24 V AC ... 35 V AC)

Extra-low and low voltage (>60 V DC, >35 V AC)

IEC 61140

III

II (installed in a suitable housing with at least IP54 protec-

tion)

Air and creepage distances According to IEC 60644/IEC 60664A, DIN VDE 0110 and

EN 50178/IEC 62103, DIN VDE 0160

Housing material Plastic, PVC-free, PBT and others, self-extinguishing (V0)

Pollution degree according to EN 50178 2; condensation not permitted during operation

Overvoltage category

Protective extra-low voltage (24 V DC ... 60 V DC,

24 V AC ... 35 V AC)

Extra-low and low voltage (>60 V DC, >35 V AC)

II

III
