IL SYS INST UM E

136 / 188 Phoenix Contact

6452_en_11

12.3.2 Supply at power terminals and boost terminals

To ensure electrical isolation through the entire station, make sure that the power termi-

nals and boost terminals are also supplied separately.

Figure 12-6 Supply of the power terminals and boost terminals using two separate

power supply units

BK

U

(U , U)

BK

L ANA

U/U

MS

24 V

0 V

24 V

0 V

PWR IN

U/U

MS

24 V

0 V

PWR IN/R/L

24 V

0 V

U

(U , U)

24V

L ANA

PWR IN/R

U/U

MS

24 V

0 V

24 V

0 V

U

(U , U)

24V

L ANA

24 V DC

... ... ...

Table 12-3 Inline power terminals and boost terminals

Type Supply of

U

M

/U

S

U

24V

(U

L

, U

ANA

)

IB IL 24 PWR IN-PAC X –

IB IL 24 PWR IN/2-F(-D)-PAC X –

IB IL 24 PWR IN/R-PAC X X

IB IL 24 PWR IN/R/L-0.8A-PAC – X
