IL SYS INST UM E
100 / 188 Phoenix Contact
6452_en_11
9.2 Indicators on Inline Block IO modules
An Inline Block IO module can be divided into the function areas bus system, supply, and
I/O. Local diagnostic and/or status indicators are assigned to each function area.
9.2.1 Indicators in the bus system function area (BUS)
For the meaning of the diagnostic and status indicators in the bus system function
area (BUS in Figure 9-6 on page 101) of the modules, please refer to the corre-
sponding documentation.
