38/46 PHOENIX CONTACT

4083_en_C

Surge IEC 61850-3 clause 6.7.3, IEC 61000-4-5,

IEEE 1613.1 clause 6

Signal ports: ±2 kV LE, ±1 kV LL

Power ports (AC or DC): ±4 kV LE, ±2 kV LL

Conducted disturbance induced by RF fields IEC 61850-3 clause 6.7.3, IEC 61000-4-6, IEEE 1613.1

clause 9, 10 V

Main frequency voltage, common mode disturbances IEC 61850-3 clause 6.7.3, IEC 61000-4-16, IEEE 1613.1

clause 12, 30 V continuous, 300 V 1 s

Power frequency magnetic field IEC 61850-3 clause 6.7.3, IEC 61000-4-8, IEEE 1613.1

clause 10, 100 A/m continuous, 1000 A/m for 3 s

Voltage dips and drops (AC/DC) IEC 61850-3 clause 6.7.3, IEC 61000-4-29, IEC 61000-4-

Damped oscillatory magnetic field IEEE 1613.1 clause 11, IEC 61000-4-10, 100 A/m (peak)

Flammability V1, IEC 61850-3 clause 6.6.6

Environmental specifications and approvals according to IEC 61850-3 Ed 2, IEEE 1613

Ethernet standards

IEEE IEEE 802.3 for 10Base-T

IEEE 802.3u for 100Base-Tx and 100Base-Fx

IEEE 802.3ab for 1000Base-T

IEEE 802.z for 1000Base-X

IEEE 802.3ae for 10Gigabit Ethernet

IEEE 802.3x for flow control

IEEE 802.3ad for LACP (Link aggregation control protocol)

IEEE 802.3Q - 2014 bridged networks

IEEE 802.1-2010 Port based network access control

IEEE 802.1AB - 2016 Station and media access connectiv-

ity discovery (LLDP)

IEEE 802.1AX Link aggregation

IEEE 1588 v2 PTP, Transparent clock operation with

power profile
