36/46 PHOENIX CONTACT

4083_en_C

General

Housing material Satin coated steel

Degree of protection IP20

Dimensions (W x H x D) 482.05 x 44.00 x 449.50 mm

Weight 9.8 kg

Ambient temperature, operating (EN 60068-2-1 and

EN 60068-2-2)

-40 … 85°C

<85°C Type tested for 16 h

Ambient temperature, storage (EN 60068-2-14) -40 … 85°C

Permissible humidity, non-condensing (EN 60068-2-30) 5 … 95%

Air pressure, operation 86 … 106 kPa (up to 2000 m)

Overvoltage category II

Pollution degree II

Shock test (IEC 60255-21-2, Class 1) 15g

Vibration (IEC 60255-21-1, Class 1) 1g

Seismic (Single axis sweep) Class 1

Free fall 1 m

Compute modules have an ambient operating temperature of -40 … 75°C

Diagnostics

LCD (front access) Individual port status for installed port/line modules

Power 2x, power status for installed power supply modules

Port LEDs (back access) Individual port status for activity

Packet switching characteristics

Mac address table size (entries) 16 k

Priority queue 8

Switch packet processing Store and forward

Latency 7 µs (64-byte packets)

Switching bandwidth 128 Gbps

Jumbo frame support <9216 bytes
