C 4 Validation

Checklist for validating theFL PN/PN SDIO-2TX/2TX safe PROFINET gateway

Device type/equipment identification

Version: HW/FW Date

Test engineer 1 Test engineer 2

Remark

No. Requirement (mandatory) Ye s Remark

1 Have all the mandatory requirements for the "Planning" checklist been

met?

2 Have all the mandatory requirements for the "Mounting and electrical

installation" checklist been met?

3 Have all the mandatory requirements for the "Startup, restart after

replacing, and parameterizing the safe PROFINET gateway" checklist

been met?

4 Does the safety integrity (SIL, PL, Cat.) of the safety components

involved in the safety function correspond to the requirements?

5 Has the response time (SFRT) for each safety function that is to be

implemented been calculated individually?

6 Have measures for preventing unintentional machine startup/restart

been implemented?

7 Has a function test been performed to check all safety functions, in

which the device is involved?

8 Have measures been taken to achieve the required safety integrity

level?

9 Does the voltage supply correspond to the specifications for the

protective extra-low voltage in accordance with PELV?

10 Is external fuse protection of the device implemented (according to the

specifications in this user manual for supply voltage UM)?

11 Have measures been taken to prevent simple manipulation?

12 Have measures been taken to prevent RJ45 plugs being mixed up?

13 Is the print on the device and labeling legible, so that the device used

can be identified as such?

14 Have the address settings/process data settings and variable

declarations been parameterized?

15 Following device replacement, have device names been assigned

according to the application, the use of the same name avoided, and the

required PROFIsafe addresses set according to the specifications?

Date Signature (test engineer 1)

Date Signature (test engineer 2)
