8220_en_06 PHOENIX CONTACT 81

C Appendix: Checklists

Archive the completed checklists to use as reference for recurring tests.

The checklists do not replace the validation, initial startup, and regular testing performed by

qualified personnel.

The following section of a checklist shows an example of a completed checklist.

NOTE:

The checklists listed in this section provide support during the planning, mounting and

electrical installation, startup, parameterization, and validation of the FL PN/PN SDIO-

2TX/2TX and the PROFIsafe system.

These checklists may be used as additional planning documentation and/or as additional

verification to ensure the steps in the specified phase are carried out carefully.

The checklists do not claim to be complete.

Observe the applicable standards for your application and, based on these, create

individual specific checklists for your system/machine.

For more detailed information, please refer to the BGIA report “Functional safety of

machine controls” (see “Documentation” on page 66).

Checklist . . .

Device type/equipment identification FL PN/PN SDIO-2TX/2TX/BK15NA11

Version: HW/FW/COP FW

SPNS

01/46F/360

10/235

Date March 7, 2005

Editor John Smith Test engineer Jane Brown

Remark System XXX has been checked for engine hood production

No. Requirement Ye s Remark

X . . .

Key:

Equipment identification Enter the device type and/or the equipment identification for the relevant device.

Version: HW/FW/COP FW

SPNS

Enter the hardware, firmware, COP firmware, and SPNS version of the device

(see Figure 2-3 on page 28).

Date Enter the date on which you began to fill in this checklist.

Test engineer 1/2 Enter the names of the test engineers.

Remark Enter a remark, if necessary.

Requirement (mandatory) These requirements must be met for a safety application, in order to complete the relevant

phase using the checklist.

Requirement (optional) These requirements are optional. For points that are not met (No), please enter an

appropriate remark in the relevant field.
