FL PN/PN SDIO-2TX/2TX

72

PHOENIX CONTACT 8220_en_06

Key:

The following table provides an overview of possible address settings:

1, 2, 3, 4 PROFINET systems

IOC PROFINET IO controller

F_Source_Add

x

F-Source Addresses (F-Parameters)

PROFIsafe source addresses; addresses of the safe PROFINET

controllers in the various PROFINET systems

F_Dest_Add

y

F-Destination Addresses (F-Parameters)

PROFIsafe destination addresses; addresses of the safe devices

(PROFIsafe devices)

SG

n

Safe PROFINET gateways

Table B-1 Possible PROFIsafe addresses in coupled PROFINET/PROFIsafe

systems

PROFINET system

F_Source_Add

1

F_Source_Add

2

F_Source_Add

3

F_Source_Add

4

F_Dest_Add

1a

F_Dest_Add

1b

F_Dest_Add

1c

F_Dest_Add

2

F_Dest_Add

3

F_Dest_Add

4

Addresses available

for additional

PROFIsafe devices

in the

corresponding

PROFINET system

1 1024 – – – 2 4 6 (3) (5) (7) 1, 8, 9, 10, 11, 12, ...

2 – 1025 – – (2) – – 3 – – 1, 4, 5, 6, 7, 8, 9, 10 ...

3 – – 1026 – – (4) – – 5 – 1, 2, 3, 6, 7, 8, 9, 10, ...

4 – – – 1027 – – (6) – – 7 1, 2, 3, 4, 5, 8, 9, 10, ...
