FL PN/PN SDIO-2TX/2TX

PHOENIX CONTACT 8220_en_06

F_Source_Address F-Parameter (F_Source_Add for short);

PROFIsafe source address, address of the safe PROFINET controller (SPNS)

F_Destination_Address F-Parameter (F_Dest_Add for short);

PROFIsafe destination address; address of the safe device (PROFIsafe device)

iParameter Individual safety parameter of a device

Passivation If the safety module detects an error, it switches the affected channel or all channels of the

module to the safe state; the channels are then passivated. The detected errors are

indicated at the safe controller.

For a safe input module when passivation is enabled, instead of the process values present

at the safe inputs, substitute values (0) are provided for the safety program.

For a safe output module when passivation is enabled, instead of the output values provided

by the safety program, substitute values (0) are transferred to the safe outputs.

PROFIsafe Safety-related bus profile based on PROFIBUS DP or PROFINET. It defines the

communication between a safety program and the safe I/O device in a safe system.

PROFIsafe address Each safe module has a PROFIsafe address. This address must be set on the safety

module via DIP switches and then configured in the configuration tool for the safe controller

used.

PROFIsafe

monitoring time

Monitoring time for safety-related communication between the safe PROFINET controller

(SPNS) and safe I/O devices.

This time is parameterized in the F_WD_Time F-Parameter.
