FL PN/PN SDIO-2TX/2TX

PHOENIX CONTACT 8220_en_06

Safety characteristics according to DIN EN 62061

Safety integrity level claim limit (SIL CL) 3, maximum

Safe failure fraction (SFF) 99%

Probability of a dangerous failure per hour for the entire

module (PFH

)

1 x 10

-9

Hardware fault tolerance (HFT) of the module 1

Permissible duration of use 20 years

Safety characteristics according to EN ISO 13849

Performance level (PL) e, maximum

Category 4, maximum

Probability of a dangerous failure per hour for the entire

module (PFH

)

1 x 10

-9

Diagnostic coverage (DC) 99%

Mean time to dangerous failure (MTTF

) 100 years

Conformance with EMC Directive 2014/30/EU

Noise immunity test according to EN 61000-6-2

Electrostatic discharge (ESD) EN 61000-4-2/

IEC 61000-4-2

Criterion A

6 kV contact discharge

8 kV air discharge

Electromagnetic fields EN 61000-4-3

IEC 61000-4-3

Criterion A

Field strength: 10 V/m

Fast transients (burst) EN 61000-4-4/

IEC 61000-4-4

Criterion A

Supply lines: 2 kV

Signal/data lines: 2 kV

Transient overvoltages (surge) EN 61000-4-5

IEC 61000-4-5

Criterion A

Signal/data lines: 1 kV

Supply lines: 0.5 kV

Conducted disturbance variables EN 61000-4-6

IEC 61000-4-6

Criterion A

Test voltage: 10 V

Noise emission test according to EN 61000-6-4 Class A

Approvals

For the latest approvals, please visit phoenixcontact.net/product

/2700651.
