Device overview

111433_en_00 Phoenix Contact 13 / 78

2.4.2 Devices with digital output (ECM-UC-...-MRTU and ...-MTCP)

Figure 2-2 Operating and indication elements of ECM-UC-...-MRTU and ...-MTCP

1. Cable feed-through

2. LED green/red DIAG: Power supply/currents

3. USI interface for parameterization

4. Metal lock for fastening to the DIN rail

Ord.No. 11 91 986 ECM-UC-100A-MRTU

2.1 2.2 2.3 2.4

4.1 4.2 4.3 4.4

DIAG

USI

2.1

2.2

2.3

2.4

www.phoenixcontact.com

ECM-UC-100A-MRTU

Ord.-No.: 1191986

PHOENIX CONTACT GmbH & Co.KG

Flachsmarktstr. 8

32825 Blomberg, Germany

Current Transducer for AC/DC and distorted currents

Ord.No. 11 91 969 ECM-UC-10A-MRTU

2.1 2.2 2.3 2.4

4.1 4.2

4.3

4.4

6.1 6.2

6.3

6.4

DIAG

USI

2.1

2.2

2.3

2.4

www.phoenixcontact.com

ECM-UC-10A-MRTU

Ord.-No.: 1191969

PHOENIX CONTACT GmbH & Co.KG

Flachsmarktstr. 8

32825 Blomberg, Germany

Current Transducer for AC/DC and distorted currents

1

4

2

3
