Control panel

109908_en_02 Phoenix Contact 71 / 150

Table 9-4 Options and their description as of version 1.03

ID Designation Display Setting range Description

1 Motor rated frequency 1. rF - motor rated

frequency

0Hz ... 500 Hz Set the motor rated frequency in accordance

with the rating plate specifications,

see “Motor rated frequency” on page79.

2 Motor rated voltage 2. rv - motor rated

voltage

1-phase device:

110 V ...240 V

3-phase device:

220 V ... 480 V

Set the motor rated voltage in accordance with

the rating plate specifications,

see “Motor rated voltage” on page 80.

3 Maximum value of the

frequency command

3. hF - highest output

frequency

0Hz ... 500 Hz Set the maximum value of the SPEED1 and

SPEED2 frequency command,

see “Highest output frequency” on page 80

4 Carrier frequency on the

output side

4. PF - pulse frequency 4 kHz

8 kHz

16 kHz

AUTO

Set the carrier frequency on the output side,

see “Carrier frequency” on page81

5 U/f characteristic curve 5. vF - vF wave form Linear

Square

Select the U/f characteristic curve,

see “U/f characteristic curve” on page83

6 Start boost 6. bo - start boost 0% ... 10% Set an increased output torque,

see “Start boost” on page83

7 Voltage lift 7. vL - voltage lift 0% ... 10% Set the total output voltage,

see “Voltage lift” on page 84

8 Slip compensation 8. Sc - slip

compensation

0% ... 10% Set the slip compensation,

see “Slip compensation” on page84

9 PTC/AI, thermal contact, and

thermistor relay

9. AI - AI - tc active no

tconc

tcono

Activate and set the analog input,

see “PTC/AI, thermal contact, and thermistor

relay” on page 85

10 Analog input 10. cv - AI input mode volt

curr

Set the input circuit,

see “Analog input” on page 87

11 Lowest output frequency 11. LF - Lowest output

frequency

Lowest output fre-

quency

Set the lowest output frequency,

see “Lowest output frequency” on page 87

12 Parameter lock 12. PL - parameter lock Yes

Activate the parameter lock,

see “Parameter lock” on page 88

13 Parameter reset 13.rES - parameter reset Yes

Reset to default settings,

see “Parameter reset” on page 88

14 Identity code 14. Id - identity code - CONTACTRONSpeed Starter type,

see “Identity code” on page89

15 Firmware version 15. vEr -firmware

version

- Firmware version of the

CONTACTRONSpeed Starter,

see “Firmware version” on page 89
